Features
![]() Air is drawn from the top and bottom of the deck, improving grass lift and delivering a superior cut. |
![]() Convenient blade engagement. Simply pull a switch on the control panel. |
![]() The stamped cutting deck is reinforced with heavy flat-stock steel for added strength and durability on the leading edge and trim side. (48″ shown) |
![]() Heavy cast front axle provides superior balance and stability, even with a collector. Pivoting action helps smooth out rough terrain. |
Specifications
Drive System |
Transmission |
|||
Drive method | Pedal-Operated | Transmission type | Hydrostatic | |
Speed Reverse Max | 2.2 mph | Transmission manufacturer | Tuff Torq | |
Speed Reverse Min | 0 mph | |||
Cutting Deck |
Equipment |
|||
Cutting Width | 48″ | Seat material | Vinyl | |
Nose Roller | Yes | Front-End Protection | Available as accessory | |
Greasable Mandrels | Yes | Hour Meter | Digital w/ pre-programmed service intervals | |
Anti-Scalp Wheels | 4 | Seat back height | High 15” | |
Steering wheel type | Deluxe Overmolded | |||
Collector | Available as accessory | |||
Engine |
||||
Engine manufacturer | Briggs & Stratton | |||
Engine name | Endurance Series V-Twin | |||
Cylinders | 2 | |||
Generator | 16A | |||
Power Output | 24 hp | |||
Fuel Type | Gasoline | |||
Fuel tank volume (with reserve) | 3 gal (US) | |||
Oil Filter | Yes |
