Features
|
![]() Adjustable Oil Pump Allows you to control oil flow depending on application and weather conditions. |
![]() AutoTune AutoTune gives optimal engine performance throughout automatic engine setting. No time spent on carburetor adjustments. It compensates for different fuels, altitude, humidity, temperature and clogged air filter. |
|
Specifications
Lubricant |
Sound and Noise |
|||
Oil tank volume | 0.42 US pint | Sound power level, guaranteed (LWA) | 116 dB(A) | |
Oil pump type | Adjustable Flow | Sound power level, measured | 114 dB(A) | |
Oil pump capacity max | 9 ml/min | Sound pressure level at operators ear | 104 dB(A) | |
Oil pump capacity min | 3 ml/min | |||
Vibration |
Overall Dimensions |
|||
Equivalent vibration level (ahv, eq) front handle | 3.1 m/s² | Weight (excl. cutting equipment) | 8.6 lbs | |
Equivalent vibration level (ahv, eq) rear handle | 3.2 m/s² | |||
Engine |
Equipment |
|||
Cylinder Displacement | 37.7 cm³ | Recommended bar length, max | 16 in | |
Cylinder displacement | 2.3 cu.in | Recommended bar length, min | 12 in | |
Power output | 2.4 hp | Chain pitch | 3/8” | |
Maximum power speed | 10200 rpm | Chain gauge | .050 in | |
Fuel tank volume | 0.72 US pint | Chain speed at max power | 63.65 fts | |
Idling speed | 3000 rpm | Chain speed at 133% of maximum engine power speed | 84.65 fts | |
Spark plug | NGK CMR6H | |||
Electrode gap | 0.02 in | |||
Torque, max. | 1.7 Nm | |||
Fuel consumption | 464 g/kWh |
