Features
|
NEMA 14-60 receptacle |
100% copper windings |
| Large 15 gallon, non-corrosive fuel tank |
Industrial powder coat paint |
|
NEMA L14-30 receptacle |
2 NEMA 5-20 duplex receptacles |
| Capacitor excitation |
Brushless operation |
|
Four-wheel dolly kit standard |
Vibration isolation for smooth operation |
| Full receptacle package with circuit breaker protection |
Heavy duty wrap around tubular steel cradle |
|
Dampers, skewed rotors for less than 5% harmonic distortion |
|
Specifications
| Max Power Rating | 12000 |
| Cont. Power Rating | 10800 |
| Voltage | 120/240 Volt 1 PH |
| Cont. Current Rating | 90/45 amps |
| Motor Starting Ability (Code G) | 5 hp |
| Engine Make/Model | Honda GX630 |
| Displacement/Type | 688 cc/OHV |
| Cylinder Sleeves | Cast Iron |
| Conserv-R Automatic Idle Control | N/A |
| Fuel Type | Gasoline Natural Gas LP Gas |
| Starting System | Electric |
| Fuel Tank Capacity | 15 gal |
| Low Oil Protection | Standard |
| Running Time-Full Load | 9.0 hrs |
| Running Time-Half Load | 14.5 hrs |
| Hour Meter | N/A |
| 120 Volt Receptacles | 4x20A NEMA 5-20 |
| 240 Volt Receptacles | None |
| 120/240 Volt Receptacles | 1x30A Locking NEMA L14-30 1x60A NEMA 14-60 |
| Switchless Full Power | N/A |
| Dimensions | 44.7x36x33 in |
| Shipping Weight | 460 lbs |
| DB Rating @ 7 Meters | 78 dba |
| CSA Approved | No |
| CARB Approved | No |
| Country Of Origin | USA |
