Features
| Air Injection Centrifugal air cleaning system removes larger dust and debris particles before reaching the air filter. This results in reduced air filter cleanings and improved engine life. | Adjustable oil pump Allows you to control oil flow depending on application and weather conditions. |
| Quick-release air filter Facilitates cleaning and replacement of the air filter. | Side-mounted chain tensioner Easier access to chain tensioning device. |
Specifications
Engine |
|
| Power output | 6.5 hp |
| Cylinder displacement | 5.37 cu.inch |
| Maximum power speed | 9,600 rpm |
| Max engine/motor | 13,000 rpm |
| Idling speed | 2,700 rpm |
| Torque, max. | 4.7 Nm |
| Torque, max. at rpm | 6,600 rpm |
| Clutch engagement speed (±120) | 3,600 rpm |
| Fuel consumption | 476 g/kWh |
| Fuel consumption | 4.98 lbs/h |
| Spark plug | Champion RCJ7Y, NGK BPMR7A |
| Electrode gap | 0.02 in |
| Ignition module air gap | 0 in |
| Oil pump type | Automatic |
| Oil pump capacity, max | 24 ml/min |
| Oil pump capacity, min | 6 ml/min |
Equipment |
|
| Bar length (inch) | 18 in, 20 in, 24, 28 in, 32 in, 36 in |
| Recommended bar length, min | 18 in |
| Recommended bar length, max | 28 in |
| Chain type | C83, C85, H83 |
| Gauge | .058″, .063″ |
| Pitch | 3/8″ |
| Sprocket type | Rim 7 |
Dimensions |
|
| Weight (excl. cutting equipment) | 16.1 lbs |
Lubricant |
|
| Lubricant type (Engine) | Husqvarna 2 stroke or equiv. at 50:1 |
| Oil tank volume | 1.06 US pint |
| Oil tank volume | 0.5 l |
Sound and Noise |
|
| Sound power level, guaranteed (LWA) | 119 dB(A) |
| Sound power level, measured | 117 dB(A) |
| Sound pressure level at operators ear | 107 dB(A) |
Vibration |
|
| Equivalent vibration level (ahv, eq) front handle | 6.5 m/s² |
| Equivalent vibration level (ahv, eq) rear handle | 7.5 m/s² |
