Features
|
|
 Flip-up Tank Cap The flip-up tank cap is easy to open and close when refueling. |
 Air Injection Centrifugal air cleaning system removes larger dust and debris particles before reaching the air filter. This results in reduced air filter cleanings and improved engine life. |
|
Specifications
Engine |
|
| Power output | 4 hp |
| Cylinder displacement | 3.06 cu.inch |
| Maximum power speed | 10,200 rpm |
| Idling speed | 2,800 rpm |
| Torque, max. | 3.15 Nm |
| Torque, max. at rpm | 7,800 rpm |
| Clutch engagement speed (±120) | 3,900 rpm |
| Fuel consumption | 432 g/kWh |
| Fuel consumption | 2.86 lbs/h |
| Spark plug | NGK CMR6H |
| Electrode gap | 0.02 in |
| Ignition module air gap | 0.01 in |
| Oil pump type | Adjustable flow, no flow at idle |
Emission |
|
| Exhaust emissions (CO2 EU V) | 813 g/kWh |
Equipment |
|
| Bar length (inch) | 16 in, 18 in, 20 in |
| Recommended bar length, min | 13 in |
| Recommended bar length, max | 20 in |
| Chain type | S35G, SP33G |
| Pitch | .325″ |
| Sprocket type | Rim 7 |
Dimensions |
|
| Weight (excl. cutting equipment) | 11.7 lbs |
Lubricant |
|
| Lubricant type (Engine) | Husqvarna 2 stroke or equiv. at 50:1 |
| Oil tank volume | 0.68 US pint |
| Oil tank volume | 0.32 l |
Sound and Noise |
|
| Sound power level, guaranteed (LWA) | 117 dB(A) |
| Sound power level, measured | 115 dB(A) |
| Sound pressure level at operators ear | 107 dB(A) |
Vibration |
|
| Equivalent vibration level (ahv, eq) front handle | 3.3 m/s² |
| Equivalent vibration level (ahv, eq) rear handle | 4.9 m/s² |
