Features
|
![]() Air Injection Centrifugal air cleaning system removes larger dust and debris particles before reaching the air filter. This results in reduced air filter cleanings and improved engine life. |
![]() LowVib® System designed to reduce vibration levels to the operator, which lessens fatigue. |
|
Specifications
Lubricant |
Sound and Noise |
|||
Oil tank volume | 0.53 US pint | Sound power level, guaranteed (LWA) | 114 dB(A) | |
Oil pump type | Fixed Flow | Sound power level, measured | 112 dB(A) | |
Oil pump capacity max | 13 ml/min | Sound pressure level at operators ear | 102 dB(A) | |
Oil pump capacity min | 13 ml/min | |||
Vibration |
Overall Dimensions |
|||
Equivalent vibration level (ahv, eq) front handle | 3.8 m/s² | Weight (excl. cutting equipment) | 9.2 lbs | |
Equivalent vibration level (ahv, eq) rear handle | 4.2 m/s² | |||
Engine |
Equipment |
|||
Cylinder Displacement | 40.9 cm³ | Recommended bar length, max | 18 in | |
Cylinder displacement | 2.49 cu.in | Recommended bar length, min | 13 in | |
Power output | 2.15 hp | Chain pitch | .325” | |
Maximum power speed | 9000 rpm | Chain gauge | .050 in | |
Fuel tank volume | 0.78 US pint | Chain speed at max power | 56.9 fts | |
Idling speed | 2900 rpm | Chain speed at 133% of maximum engine power speed | 75.46 fts | |
Spark plug | Champion RCJ7Y, NGK BPMR7A | |||
Electrode gap | 0.02 in | |||
Torque, max. | 2 Nm | |||
Fuel Consumption | 650 g/kWh |
