Features
|
2″ hitch coupler |
Auto-idle |
| Heavy duty steel fenders |
Rubber torsion axle |
|
Heavy duty 4 bolt trailer hubs for towing |
Long lasting high gloss powder coat finish |
| 16 long lasting carrier bolts |
Nylon sleeved high pressure hoses |
|
Max towing speed: 45 MPH unpaved / 55 MPH paved |
Spring loaded vertical and horizontal rail locks |
| Heavy duty crank down wheel jack for easy moving |
High pressure hoses on both the pressure & return side |
Specifications
| Cylinder | 24″ L x 5″ Dia. |
| Valve | Valve 3 Position with Auto Return |
| Pump | 16 GPM Barnes, 2-Stage, 3500 PSI |
| Hydraulic System | 12 Gallons System Total |
| Engine Options | 270cc Honda GX |
| Bed Height | 34.5″ |
| Beam | 6″ reinforced I-Beam |
| Tires | 4.80″ X 12″ Highway Rated |
| Log Opening | 25” |
| Cycle Time | Appox. 14 Seconds Complete Cycle |
| Splitting Force | Appox. 37 tons |
| Weight | 725 lbs. |
