Features
|
2″ hitch coupler |
Log Dislodger Standard |
| Heavy duty steel fenders |
Heavy duty 2 x 3 box tube tongue |
|
Heavy duty 4 bolt trailer hubs for towing |
Long lasting high gloss powder coat finish |
| E-Z lift hinge one hand lift to vertical operation |
Spring loaded vertical and horizontal rail locks |
|
Heavy duty crank down wheel jack for easy moving |
High pressure hoses on both the pressure & return side |
|
Duro-Glide Rail System for extended use applications |
|
Specifications
| Cylinder | 4.5″ x 24″ clevis type, 2.00″ rod |
| Valve | 3 Position with Auto Return |
| Pump | 16 GPM HI-LO 2 Stage |
| Hydraulic System | 9.5 Gallons System Total |
| Engine Options | 270cc Honda GX |
| Bed Height | 33″ |
| Beam | Formed steel with 1/2″ x 6″ top plate, close tolerance cold roll steel |
| Tires | 4.80 X 8.00 Highway Rated |
| Log Opening | 25” |
| Cycle Time | Appox. 12 Seconds Complete Cycle |
| Splitting Force | Appox. 26 tons |
| Weight | 685 lbs. |
