Features
|
2″ hitch coupler |
Log Dislodger Standard |
| Heavy duty steel fenders |
Heavy duty 2 x 3 box tube tongue |
|
Heavy duty 4 bolt trailer hubs for towing |
Long lasting high gloss powder coat finish |
| E-Z lift hinge one hand lift to vertical operation |
Spring loaded vertical and horizontal rail locks |
|
Heavy duty crank down wheel jack for easy moving |
High pressure hoses on both the pressure & return side |
Specifications
| Cylinder | 4″ X 24″ clevis type, 1.75″ rod |
| Valve | 3 Position with Auto Return |
| Pump | 11 GPM HI-LO 2 Stage |
| Hydraulic System | 9.5 Gallons System Total |
| Engine Options | 160cc Honda GX |
| Bed Height | 33″ |
| Beam | 6″ heavy-duty formed steel |
| Tires | 4.80 X 8.00 Highway Rated |
| Log Opening | 25” |
| Cycle Time | Appox. 12 Seconds Complete Cycle |
| Splitting Force | Appox. 22 tons |
| Weight | 660 lbs. |
