Features
|
2″ hitch coupler |
9″ high wedge for big jobs |
| Highway rated 12″ tires for clearance |
Heavy-duty steel fenders |
|
Heavy duty 4 bolt trailer hubs for towing |
Long lasting high gloss powder coat finish |
| High pressure hoses on both the pressure & return side |
Available with an optional 4-way wedge for production |
Specifications
| Cylinder | 5″ X 24″ clevis type X 2″ rod |
| Valve | 3 Position with Auto Return |
| Pump | 16 GPM HI-LO 2 Stage |
| Hydraulic System | 9.5 Gallons System Total |
| Engine Options | 270cc Honda GX |
| Bed Height | 28″ |
| Beam | 6″ Heavy-duty formed steel |
| Tires | 4.80 X 12.00 Highway Rated |
| Log Opening | 25” |
| Cycle Time | Appox. 16 Seconds Complete Cycle |
| Splitting Force | Appox. 30 tons |
| Weight | 650 lbs. |
